Place of Origin: | CHINA |
Brand Name: | OEM |
Certification: | ISO9001, CE, SGS |
Minimum Order Quantity: | Negotiable |
---|---|
Price: | Negotiation |
Packaging Details: | Multiple packaging |
Delivery Time: | 10-15 working days |
Payment Terms: | T/T, L/C, T/T, Western Union |
Supply Ability: | 10000PCS |
Product Name: | 1w Mini Solar Panel Module | Size: | 125*63*3mm/Customized |
---|---|---|---|
Voltage: | 6V/Customized | Weight: | 53g |
Current: | 580~600mA | Surface Material: | Glossy/PET/Epoxy/Customized |
Shape: | Round/Square/Customized | Logo: | OEM Customized |
Application: | Solar LED Light / Solar Toys | Connector: | DC, SAE,Andrewson,Aligator Clips,wire Etc. |
Cell: | High Efficiency 5BB 6BB Mono Poly Cells | ||
High Light: | Mono And Polycrystalline Solar Cells,1W Epoxy Resin Solar Panel,Mini Solar Panel 5v |
Quality control and safety:
1. Rigorous quality control meets the highest international standards.
2. High efficiency solar cells to meet the customers' requirements.
3. High quality fibergalss PCB insure the long life span of the solar panels.
4. Certificate:FCC/CE/RoHS/ErP.
Feature:
Mono-crystalline silicon and poly-crystalline silicon
Epoxy resin encapsulation, High transparent and anti-yellowing.
High-intensity PCB hardboard or glass fiber board materials, resistance to deformation.
Accord with environmental protection manufacturing process.
Inspection standard:40×1000Lux×25°C.
Accept customization.
Application scope: mobile charger, Lawn lamp, portable lantern, street lamp, Traffic lights, Christmas lights, walkman,toys and so on.
DC Storage Battery | Mini Solar Panel |
1.2V | 2~2.5V |
2.4V | 3.5~4V |
3.6V | 5~6V |
3.7V | 5.5~6V |
4V | 6~7V |
4.8V | 7~8V |
6V | 8~9V |
12V | 16~18V |
Product Details:
Item | Solar Cells | Monocrystalline/Polycrystalline |
Max.power | 1 Watt | |
Voltage | 6V | |
Current | 580~600mA | |
Dimensions | 125*63*3 mm | |
Weight | 41 g | |
Output interface | DC5521/SAE/DualUSB(standard)/Dual Voltage(DC5521&USBD) | |
Material | Epoxy resin + EVA + Solar Cell + PCB/PET Lamination + EVA + Solar Cell +PCB | |
Tips | We accept customized any Size, Wattage, Voltage, Shape and Logo etc. |
Provide you with high conversion rate and incredibly efficient output.
Excellent performance even under the weak sunlight.
Unique processing to make the panel durable enough to anti the snow, and convenient enough to set.
Unique technology to avoid water freezing and deformation within the frame.
Elegant figure and small size, easy to carry.
Application: to charge cell phones, for home lighting and different kinds of low-power appliances, for science projects, for solar powered water pump, small solar power system, etc
