| Place of Origin: | CHINA |
| Brand Name: | OEM |
| Certification: | ISO9001, CE, SGS |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Multiple packaging |
| Delivery Time: | 10-15 working days |
| Payment Terms: | T/T, L/C, T/T, Western Union |
| Supply Ability: | 10000PCS |
| Color: | Dark Blue | Junction Box: | IP67 |
|---|---|---|---|
| Connector: | MC4 Compatible Connector | Efficiency: | 15-19.51% |
| Solar Cell: | A Grade | Feature: | High Capacity |
| Size: | 1640*992*40mm | Frame: | Aluminum Alloy |
| Glass: | Ultrathin And High Transparency Solar Glass | Type: | Standard Solar Panel |
| Single Package Size : | 164X99.2X4 Cm | Single Gross Weight: | 18.001 Kg |
| Applicaton: | Commercial / Home | ||
| High Light: | 295W Polycrystalline PV Module,Polycrystalline A Grade Solar Panel,290W A Grade Solar Panel |
||
|
Model No:
|
MS-P260(60)/MS-P265(60)/MS-P270(60)/MS-P275(60)
MS-P280(60)/MS-P285(60)/MS-P290(60)/MS-P295(60)
|
|
Type of cell
|
polycrystalline
|
|
Maximum power (Wp)
|
260W/265W/270W/275W/280W/285W/290W/295W
|
|
Maximum power voltage (V)
|
31.05V/31.10V/31.14V/31.18V/31.22V/31.26V/31.30V/
31.34V
|
|
Maximum power current (A)
|
8.37A/8.52A/8.67A/8.82A/8.97A/9.12A/9.27A/9.47A
|
|
Open circuit voltage (V)
|
37.80V/37.82V/37.86V/37.88V/37.90V/37.94V/37.98V/
38.02V
|
|
Short circuit current (A)
|
8.71A/8.87A/9.10A/9.18A/9.34A/9.50A/9.64A/9.85A
|
|
Number of cells (Pcs)
|
60
|
|
Size of module (mm)
|
1640*992*40mm(156*156mm cell)
|
|
Temperature coefficients of Isc (%)
|
+0.1/ ℃
|
|
Temperature coefficients of Voc (%)
|
-0.38/ ℃
|
|
Temperature coefficients of Pm (%)
|
-0.47/ ℃
|
|
Temperature coefficients of Im (%)
|
+0.1/ ℃
|
|
Temperature coefficients of Vm (%)
|
-0.38/ ℃
|
|
Temperature Range
|
-40℃~+80℃
|
|
Frame (Material, Corners, etc.)
|
Aluminum
|
|
Standard Test Conditions
|
AM1.5 100mW/cm2 25℃
|
|
Junction Box Type
|
( TUV )
|
